Overview
VSI sand making machine, also known as impact crusher, can make various rocks, sand and gravel, and river pebbles into construction sand that meets various particle sizes. The sand particle size is uniform and the compressive strength is high, which meets the requirements of construction compared to natural sand and ordinary hammer sand making machines. The equipment has the characteristics of reliable performance, reasonable design, easy operation, and high work efficiency. Widely applicable to the medium and fine crushing of various hard and brittle materials such as rocks, abrasives, refractory materials, cement clinker, quartz, iron ore, concrete aggregates, etc. (for making sand particles)
Learn More About 6X Vertical Shaft Impact Crusher
1、 The impeller structure adopts a brand new four feeding port design, which improves the material throughput and increases the crushing efficiency of the same material by about 20% compared to the three port impeller.
2、 By adjusting the structure and process of the impeller part, the service life of the impeller part has been increased by 30-200% compared to previous equipment under the same material crushing conditions.
3、 The transmission part of the equipment adopts a special sealing structure to prevent oil leakage from the bearing cylinder, and has obtained 2 national patents; Imported bearings are used to reduce transmission system failures.
4、 Add a lifting device to facilitate customer maintenance of the equipment.
5、 The simple design of the lower structure of the machine effectively prevents blockage of the lower part of the machine when the material contains too much water.
6、 Adopting the "stone to stone" working mode reduces the types of wear-resistant materials used and lowers customer production costs.
Working Principle
1. Excellent particle size of the product: The product is made in a cubic shape, with good particle size, reasonable grading, and adjustable fineness modulus, especially suitable for manual sand making and stone shaping.
2. Low wear and tear of vulnerable parts: The optimized design of the crushing chamber reduces the friction between materials and wear-resistant components, directly reducing the equipment's operating costs.
3. Long service life: Equipped with a standard thin oil lubrication station, it effectively solves problems such as bearing heating, keeps the spindle bearings at a constant temperature, and extends maintenance cycles and service life.
4. Easy to operate and maintain: The equipment is lightweight, has various installation methods, and is easy to operate and use. Once the specific purpose is identified, only minor adjustments are needed to fully utilize its performance. Equipped with a hydraulic opening device, it makes the maintenance and replacement of components inside the crushing chamber more convenient and efficient, saving time and manpower.
5. Multi functional application, strong flexibility: With multiple crushing chamber types, it can easily achieve the conversion between "stone to stone" and "stone to iron", solving the problem of multi-purpose use of one machine and meeting the different needs of users, such as manual sand making, crushed stone shaping, abrasive materials, etc
Specifications - Technical Data
Type | VSI6X1263 | VSI6X1150 | VSI6X1040 | VSI6X9026 |
|---|
Central feed processing capability | crusher | 454-486 | 344-368 | 264-283 | 167-179 |
| shaping | 545-583 | 413-442 | 317-342 | 200-215 |
Maximum feed size | crusher | ≤50 | ≤45 | ≤40 | ≤35 |
| shaping | ≤60 | ≤55 | ≤50 | ≤45 |
Rotation speed | 900-1200 | 1000-1300 | 1100-1400 | 1200-1500 |
Power | 2×315(400) | 2×250(350) | 2×200(270) | 2×132(175) |
Dimension(L*W*H) (mm) | 5700×2980×4190 | 5500×2750×3950 | 5880×2560×3725 | 4640×2380×3500 |
Weight(t) | rock on rock | 20 | 17.6 | 14.1 | 12.6 |
| rock on steel | 23 | 20 | 15.8 | 14.1 |
Thin oil lubrication station | Power | 2×0.75(1) |
| Safety protection | Stop automatically without oil flow; wind cooling system; Heater system in winter |
| Flow capacity（L/min） | 4.161 |
| Heater power(kW) | 4kW |
Notice:
Any change of 6X Vertical Shaft Impact Crushertechnical data shall not be advised additionally.
